element label

diagram
namespace	http://www.w3.org/1999/xhtml
type	extension of Inline
properties	content  complex mixed  true
children	a br span bdo map object img tt i b big small em strong dfn code q samp kbd var cite abbr acronym sub sup input select textarea label button ins del script
used by	group  inline.forms
attributes	Name   Type   Use   Default   Fixed   annotation id xs:ID          class xs:NMTOKENS          style StyleSheet          title Text          lang LanguageCode          lang          documentation <div> <h3>lang (as an attribute name)</h3> <p>        denotes an attribute whose value        is a language code for the natural language of the content of        any element; its value is inherited.  This name is reserved        by virtue of its definition in the XML specification.</p> </div> <div> <h4>Notes</h4> <p>       Attempting to install the relevant ISO 2- and 3-letter       codes as the enumerated possible values is probably never       going to be a realistic possibility.       </p> <p>       See BCP 47 at <a href="http://www.rfc-editor.org/rfc/bcp/bcp47.txt">        http://www.rfc-editor.org/rfc/bcp/bcp47.txt</a>       and the IANA language subtag registry at       <a href="http://www.iana.org/assignments/language-subtag-registry">        http://www.iana.org/assignments/language-subtag-registry</a>       for further information.      </p> <p>       The union allows for the 'un-declaration' of xml:lang with       the empty string.      </p> </div> dir derived by: xs:token          onclick Script          ondblclick Script          onmousedown Script          onmouseup Script          onmouseover Script          onmousemove Script          onmouseout Script          onkeypress Script          onkeydown Script          onkeyup Script          for xs:IDREF          accesskey Character          onfocus Script          onblur Script
annotation	documentation       Each label must not contain more than ONE field       Label elements shouldn't be nested.
source	<xs:element name="label">   <xs:annotation>     <xs:documentation>       Each label must not contain more than ONE field       Label elements shouldn't be nested.       </xs:documentation>   </xs:annotation>   <xs:complexType mixed="true">     <xs:complexContent mixed="true">       <xs:extension base="Inline">         <xs:attributeGroup ref="attrs"/>         <xs:attribute name="for" type="xs:IDREF"/>         <xs:attribute name="accesskey" type="Character"/>         <xs:attribute name="onfocus" type="Script"/>         <xs:attribute name="onblur" type="Script"/>       </xs:extension>     </xs:complexContent>   </xs:complexType> </xs:element>

attribute label/@for

type	xs:IDREF
properties	isRef  0
source	<xs:attribute name="for" type="xs:IDREF"/>

attribute label/@accesskey

type	Character
properties	isRef  0
facets	Kind  Value  annotation  length  1
source	<xs:attribute name="accesskey" type="Character"/>

attribute label/@onfocus

type	Script
properties	isRef  0
source	<xs:attribute name="onfocus" type="Script"/>

attribute label/@onblur

type	Script
properties	isRef  0
source	<xs:attribute name="onblur" type="Script"/>
